Technical Data


Tape Width
Tape Length

Dispenser
Min
Max
Min
Max
Multiple Roles
Max Tape Diameter
Core Size
Dimensions
Shipping Weight
Timesaver 852
0.25"
6mm
2"
51mm
1.0"
25mm
12"
305mm
Yes
7.5"
191mm
Any
18" L x 12"W x 8"H
45.7 x 27.9 x 20.3 cm

37 lbs.
16.8 kg
Workmaster 802
0.25"
6mm
2"
51mm
1.0"
25mm
21"*
533mm
Yes
9"
229mm
Any
25" L x 11" W x 8" H
63.5 x 29.7 x 20.3 cm
50 lbs.
22.7 kg
Workhorse 822-spl
0.25"
6mm
4.25"
108mm
1.0"
25mm
21"*
533mm
Yes
9"
229mm
Any
25" L x 13" W x 8" H
63.5 x 33 x 20.3 cm
52 lbs.
23.6 kg
PowerPro 822-6-spl
0.25"
6mm
6.25"
159mm
1.0"
25mm
21"*
533mm
Yes
9"
229mm
Any
25" L x 15" W x 8" H
63.5 x 38.1 x 20.3 cm
55 lbs.
24.9 kg
Expander 822-10-spl
0.25"
6mm

10"
254mm
1.0"
25mm
21"*
533mm
Yes
9"
229mm
Any
25" L x 19 " W x 8" H
63.5 x 48.3 x 20.3 cm
57 lbs.
25.8 kg
Protector 822-12-spl
0.25"
6mm
12"
305mm
1.0"
25mm
21"*
533mm
Yes
9"
229mm
Any
25" L x 21" W x 8" H
63.5 x 53.3 x 20.3 cm
65 lbs.
29.5 kg
* Special gearing available for tape lengths up to 43" (1,092mm)
* Extender and Brake assembly for jumbo rolls.

Other technical items to note are:

  • Air pressure requirement: 60 Psi
  • Mounting method: bench or tabletop
  • Each unit is shipped with parts list and exploded view of dispenser with operating instructions.
  • Please contact us for warranty information.
  • Please call regarding tapes that do not meet these criteria.
  • Download technical PDF
